ACEGrid® GN- PET woven geogrid with durable and environmentally friendly coating

Cost-effective reinforcement construction with environmental protection awareness

About


Woven PET Geogrids with Durable and Environmentally Friendly Coating for Soil Reinforcement

ACEGrid® GN are flexible woven geogrids composed of high tenacity polyester (PET) yarns and polymer coating to the exclusion of plasticizer for soil reinforcement applications. The geogrids provide a wide range of tensile strength, 20kN/m to 1000kN/m for uniaxial and10kN/m to 300kN/m for biaxial, with enhanced durability and as a more environmentally friendly product.

Function

Reinforcement

Reinforcement

Features

Plasticizer, halogen and heavy metal free

After longtime exposure to ultraviolet light, the plasticizers such as phthalates added for some polymer coating may degrade the coating, and release into the environment as one kind of endocrine disrupting chemicals. Furthermore, ACEGrid® GN geogrids are free of heavy metal and halogen.


Outstanding mechanic performance in the long term

With the usage of high quality material and expertise of manufacturing geogrids, ACEGrid® GN geogrids have very low elongation and excellent anti-creep performance. Moreover, ACE Geosynthetics is committed to improving the durability of the environmentally friendly product ; also, numerous tests performed by accredited laboratories have been accomplished for proving its performance including resistance to ultraviolet, acid, alkali and installation damage, etc. Along with good resistance to creep, chemicals and installation damage, the geogrids offer high Long-Term Design Strength (LTDS).


Be both green and cost-effective

It is usually regarded green products to be way too expensive, but ACEGrid® GN geogrids are not the same as you thought. With the backup of great production capacity and more than 20 years’ manufacturing experience, the quality and cost effectiveness of ACEGrid® can be basically ensured. Through investing great efforts in research & development, the cost of this green product is well confined. Therefore, with the same excellence of mechanical behaviors as the other ACEGrid® series products, ACEGrid® GN geogrids can fulfill the essentials of engineering safety and profit, and further comply with the trends of environmental protection.


It is widely known that the soil reinforcement applications using geogrids have the advantage of carbon emission reduction than traditional approaches, especially those built with steel and concrete. When we want to do more for our living environment, ACEGrid® GN geogrids now offer a “greener" alternative to the civil engineering world. The benefits of using ACEGrid® GN include:

More environmentally friendly
High quality and long-term durability to ensure structure service life
Simple and quick installation to reduce construction time and costs
